1QJM42 Hydraulic Motor
| Type | Displacement | Pressure(MPa) | Rotational Speed Range(r/min) | Rated output Torque(N.M) | Mixture power (kw) | |
| (L/rev) | Rated | Peak | ||||
| 1QJM42-2.5 | 2.56 | 20 | 31.5 | 1~250 | 7578 | 105 |
| 1QJM42-3.2 | 3.24 | 10 | 16 | 1~200 | 4850 | 90 |
| 1QJM42-4.0 | 4 | 10 | 16 | 1~160 | 5920 | 90 |
| 1QJM42-4.5 | 4.6 | 10 | 16 | 1~125 | 6808 | 90 |
2. Radial spherical piston motor with rotating shaft
3. Control Method: manual control with spool valve, manual control with screw or hydraulic control
4. Widely applicable for hydraulic transmission system of mining machinery, heavy duty transportation equipment, metallurgy machinery, petroleum mining machinery, maritime deck machinery, machine tools, light industry, plastic machinery, drilling equipment etc.
5. Very competitive price
Flow rate of QJM motors=rated speed ×displacement
| Series | QJM001 | QJM01 | QJM11 | QJM12 | QJM21 | QJM32 | QJM42 | QJM52 | QJM62 |
| Flow rate L/min | 50 | 63 | 80 | 80 | 100 | 160 | 250 | 320 | 400 |
| Outer diameter(mm) | Ø140 | Ø180 | Ø240 | Ø240 | Ø300 | Ø320 | Ø350 | Ø420 | Ø485 |
QJM series hydraulic motor’s structure principle:
The QJM hydraulic motor’s oil distribution shaft is rigidly connected with the rear cover. The rotor block uses the oil distribution shaft as
radial support and employs a stator spherical rollaway nest and steel ball as axial support. The rotor’s output shaft is an internal spline,
and the rotor block is floating. The oil distribution shaft is rigid, allowing the use of steel pipe connections for oil inlet and outlet.
